Building Support Plate Steel Truss Forming MachineIt Is A Core Automation Equipment In The Field Of Prefabricated Buildings And Steel Structure Buildings, Specifically Used For Producing Specialized Steel Bar Trusses (triangular Steel Bar Skeleton) For Floor Slabs, Greatly Improving The Efficiency And Quality Of Floor Construction, Replacing Traditional Manual Binding, And Is A Key Equipment For Modern Building Industrialization.
The Equipment Adopts A Fully Automated Production Line Design, Integrating Six Core Processes Including Steel Bar Laying, Straightening, Web Bending, Truss Assembly Welding, Automatic Cutting, And Finished Product Stacking. The Entire Process Is Controlled By PLC And Servo Driven, And Only One Person Is Needed To Be On Duty To Operate Normally. Its Workflow Is Efficient And Coherent. Firstly, The Round Steel Bars Are Automatically Laid Out And Straightened In Both Directions. Then, The Steel Bars Are Bent Into A Continuous Triangular Waveform Web Member Through A Servo System. Subsequently, One Upper Chord Bar, Two Lower Chord Bars, And The Web Member Are Accurately Positioned, Welded Into Shape By High-frequency Resistance Welding, And Finally Mechanically Cut To The Set Length. The Finished Product Is Automatically Stacked With Aggregates Without Waste And Low Noise.
The Core Advantages Of This Equipment Are Outstanding, With A Production Speed Of 16-18 M/min, High Precision In Size, Pitch, And Welding Points, And A Straight And Distortion Free Truss; Flexible Specification Switching, Able To Quickly Adapt To Truss Models Of Different Heights And Widths, With Stable Welding Without Missing Or Penetrating Galvanized Sheets. At The Same Time, It Has Intelligent Operation And Maintenance Functions, Which Can Achieve Fault Self Diagnosis, Parameter Storage, And Order Scheduling Production, And Is Energy-saving And Environmentally Friendly, Without Hydraulic Oil Pollution.
It Is Mainly Used In The Production Of Steel Truss Floor Slabs, PC Composite Panels, And High-speed Rail Double Block Sleepers. When Used In Conjunction With Floor Slabs, It Can Reduce The Amount Of Steel Reinforcement Binding On Site By 70%, Ensuring Reasonable Stress And Strong Seismic Resistance Of The Floor Slab, And Balancing Construction Efficiency And Economy. It Is Widely Used In Various Building Projects Such As High-rise Buildings, Factories, And Shopping Malls.
