Double Sided Baking Paint Keel MachineIt Is A Specialized Automated Forming Equipment In The Field Of Architectural Decoration, Designed For Mass Production Of Double-sided Painted Keel, Integrating Cold Rolling Forming And Fully Automatic Double-sided Painted Technology. Different From Ordinary Light Steel Keel Machines, It Focuses On Solving The Problems Of Uneven Surface Coating And Insufficient Anti-corrosion Of Traditional Keels. The Double-sided Painted Keel Produced Has Both Beauty And Durability, And Is The Core Supporting Production Equipment For High-end Home Decoration And Industrial Suspended Ceilings. It Is Widely Suitable For Scenarios Such As Hotels, Shopping Malls, Hospitals, And High-end Residential Buildings That Require High Aesthetic And Quality Of Suspended Ceilings.
The Core Of The Equipment Is A Double-sided Painted Keel Integrated Production Line, Which Adopts A PLC+HMI Integrated Control System Throughout The Process, Integrating The Entire Process Of "forming Baking Curing Cutting Stacking", And Only Requires One Person To Be On Duty For Stable Operation. The Production Line Process Is Coherent. Firstly, The Strip Steel Is Unrolled, Leveled, And Cold Bent Through Multiple Rolls To Form The Keel Substrate; Subsequently, It Enters The Fully Automatic Double-sided Baking Paint Station And Achieves Uniform Painting On Both Sides Of The Keel Through Electrostatic Spraying Technology, Followed By High-temperature Curing Treatment To Ensure Strong Adhesion And Resistance To Peeling Of The Paint Surface; Finally, The Finished Product Is Palletized By Servo Hydraulic Cutting And Fixed Length Cutting. Some High-end Models Can Integrate Fully Automatic Packaging Function, Achieving Unmanned Intervention Throughout The Entire Process, With No Waste And Low Loss, Ensuring Efficient And Orderly Production.
The Core Advantages Of This Equipment Are Outstanding, Combining Molding Accuracy And Baking Paint Quality. The Molding Process Adopts Siemens Closed-loop Control Servo Cutting, And The Cutting Error Can Be Controlled Within ± 0.3mm. The Keel Section Is Regular And The Size Is Uniform, And The Double-sided Bite Is Tight, Avoiding Loosening During Installation; The Baking Process Uses Environmentally Friendly Powder Coating, With Even Electrostatic Spraying, Resulting In A Smooth And Even Paint Surface Without Sagging Or Color Difference. It Has Excellent Anti-corrosion, Rust Proof, And Scratch Resistant Properties, And Its Service Life Is Extended By More Than 50% Compared To Ordinary Keels. Flexible Specification Switching, Adopting Modular Quick Change Mold Design, Mold Replacement And Parameter Calibration Can Be Completed In 15-30 Minutes. It Can Produce 38, 50, 60 Series Double-sided Painted Main And Auxiliary Bones, Suitable For More Than 80% Of The Mainstream High-end Ceiling Demand In The Market. At The Same Time, It Has The Characteristics Of Intelligent Operation And Maintenance, Energy Conservation And Environmental Protection. It Supports Real-time Parameter Adjustment And Fault Self Diagnosis. There Is No Exhaust Gas Or Wastewater Discharge In The Baking Process. The Servo System Is 30% -40% More Energy-efficient Than Traditional Hydraulic Systems. Important Components Are Made Of CR12MOV Material, With A Service Life Of Over 10 Years.
Its Application Scenarios Focus On High-end Building Decoration, Mainly Used For Ceiling Projects In Hotels, Office Buildings, Shopping Malls, Hospitals, High-end Residential Areas, Etc. The Double-sided Painted Keel Is Not Only Easy To Install, But Can Also Be Matched With Various Ceiling Panels (such As Gypsum Board, Aluminum Buckle Board) To Enhance The Overall Aesthetics Of The Ceiling. At The Same Time, It Has Good Moisture-proof And Anti-corrosion Performance, Suitable For Damp And Crowded Public Scenes. The Equipment Can Significantly Reduce Labor Costs And Coating Losses, Increase The Daily Production Capacity Of Traditional Manual Coating+forming From Thousands Of Pieces To Over 8000 Pieces, And Reduce The Scrap Rate To Below 0.5%. It Balances Production Efficiency And Product Quality, Helping Enterprises Seize The High-end Dragon Bone Market And Achieve Standardized And Standardized Production.
